La impresora Epson Ecotank L3260 se vende también con la nomenclatura Epson Ecotank ET-2820, y Ecotank ET-2821.
Se trata de una impresora multifunción que imprime hasta el tamaño A4, y que tiene un coste de impresión muy bajo debido a utilizar tanques de tinta en lugar de cartuchos.
Se trata de una maquina 3 en 1, ya que puede imprimir, escanear y hacer copias.
Con las botellas de tinta incluidas se puede imprimir 3.600 hojas con tinta negra y un total de 6.500 páginas en color.
Puedes encontrar software y drivers para estas impresoras desde la página de soporte de Epson en este enlace.
El manual de usuario en inglés puede ser descargado desde este enlace, y es válido para los modelos Epson L3260, L5290 y también los modelos Ecotank ET-2820, y ET-4800.
El manual de despiece es válido para una amplia variedad de modelos.
Estos son los siguientes: ET-2800, ET-2803, ET-2820, ET-2821, ET-2825, ET-2826, L3260, L3266, L3267, L3268, L3269.
Podéis descargar el despiece desde este enlace.
Como los códigos de pieza no van incluidos en el despiece, va el listado a continuación.
Código Referencia Descripción
| 1835978 | 100 | HOUSING,LEFT |
| 1746175 | 101 | COVER,INK EJECT |
| 1746170 | 102 | HOUSING,RIGHT |
| 1746172 | 104 | HOUSING,FRONT,RIGHT |
| 1746174 | 105 | COVER,TANK |
| 1756598 | 106 | HOPPER ASSY.,CG86,EPPI,ASP |
| 1746165 | 107 | PAPER SUPPORT |
| 1749776 | 108 | STACKER ASSY.,CG86,EPPI |
| 1866388 | 109 | COVER FRONT ASSY,CJ65,EPPI,ASP |
| 1837462 | 110 | LABEL,MODEL NAME,ET-2820 |
| 1842330 | 111 | PANEL ASSY.,CJ66,EPPI |
| 1746673 | 117 | COMPRESSION SPRING,1.83,HOPPER |
| 1746885 | 118 | LABEL,Caution,Tank,EEB WE |
| 1746899 | 119 | LABEL,Caution,Right,EEB WE |
| 1837349 | 120 | LABEL,eco tank |
| 2208560 | 200 | BOARD ASSY.,MAIN |
| 2208565 | 300 | BOARD ASSY.,POWER SUPPLY |
| 2207229 | 350 | WIRELESS LAN USB MODULE |
| 1760358 | 353 | POROUS PAD,CR,F2 |
| 1756593 | 501 | INK SYSTEM ASSY.,CG86,EPPI,ASP |
| 1840049 | 502 | SHAFT LD ASSY.,CJ67,EPPI |
| 1756597 | 503 | LEVER,DETECTOR,PE,CG86,EPPI,ASP |
| 1865783 | 504 | PGU CENTER ASSY B,CG89,EPPI |
| 1763610 | 505 | PAPER GUIDE UPPER RIGHT ASSY.,CG89,EPPI |
| 1763609 | 506 | PAPER GUIDE UPPER LEFT ASSY., CG89,EPPI |
| 2189475 | 507 | MOTOR,ASSY,CR |
| 1756596 | 508 | ARRIAGE ASSY.,CG86,EPPI,ASP |
| 2189473 | 509 | CABLE,ENCODER,CR |
| 2209094 | 510 | CABLE,HEAD,CR,F2 |
| 2209097 | 511 | MOTOR,ASSY.,PF |
| 1741749 | 512 | CLUTCH |
| 1718070 | 513 | HOLDER,CLUTCH |
| 1718063 | 514 | EXTENSION SPRING,0.137 |
| 1757294 | 515 | EXTENSION SPRING, 0.134, LEVER, DETECTOR |
| 1540008 | 516 | DOUBLE SIDE TAPE,D21,B |
| 1717901 | 520 | ROLLER,EJ |
| 1835996 | 521 | SPUR GEAR,CLUTCH,45.6 |
| 1790713 | 522 | ROLLER PF ASSY.,CG87,EPPI |
| 2208649 | 532 | BOARD ASSY.,ENCODER |
| 1749771 | 543 | LEVER CHANGE ASSY.,CG86,EPPI |
| 1718100 | 545 | HOLDER,FFC,F2 |
| 1746144 | 546 | COMBINATION GEAR,40.97,35.4 |
| 1746145 | 547 | SPUR GEAR,36 |
1866393 | 548 | STAND, SC, SUPPORT, ASY, CJ65,ASP,EPPI |
| 1746663 | 549 | FOOT,6t-2t |
| 1749766 | 550 | HOLDER STARWHEEL ASSY.,CG86,EPPI |
| 1836853 | 551 | COVER,MAIN BOARD |
| 1836854 | 552 | COVER,MOTOR,CR |
| 1746682 | 553 | POROUS PAD,CAP |
| 1754459 | 554 | FOOT,5t-15x9 |
| 1746665 | 555 | GROUNDING SPRING,ROLLER,PF |
| FA04061 | 700 | PRINT HEAD,ID1510-2 |
| 1830528 | 701 | MAINTENANCE BOX ASSY.B,CG86,EPPI |
| 1748804 | 702 | TANK SUPPLY INK ASSY.,CG86,EPPI |
| 1746677 | 703 | POROUS PAD,TANK,UPPER |
| 1746151 | 704 | PIN,POROUS PAD |
| 1746666 | 705 | POROUS PAD,PAPERGUIDE,FRONT |
| 1710162 | 706 | CAP,TANK |
| 1746005 | 707 | HINGE,CAP,TANK |
| 1758384 | 708 | ADAPTER BK ASSY.,CG89,EPPI |
| 1758383 | 709 | ADAPTER ASSY CL,CG89,EPPI |
| 1746667 | 710 | SHEET,GUIDE,TUBE |
| 1746669 | 711 | SCALE,CR,180 |
| 2208651 | 712 | BOARD ASSY.,ENCODER |
| 1571785 | 713 | SCALE,PF,B |
| 1548480 | 714 | EXTENSION SPRING,1.41 |
| 1767062 | 715 | HOLDER RETARD ASSY.,CG89,EPPI |
| 1746681 | 716 | TUBE,SUPPLY,INK |
| 1718074 | 718 | EXTENSION SPRING,0.023 |
| 1765463 | 719 | LEVER,AP SENSOR.,ASSY CG85,EPPI,ASP |
| 2164868 | 720 | PHOTO INTERRUPTER |
| 1758290 | 721 | TORSION SPRING,2.48 |
| 1756405 | 723 | EXTENSION SPRING,1.58 |
| 1803398 | 740 | AP SENSOR ASSY.B,CG85,EPPI |
| 2189471 | 741 | CABLE,ENCODER,PF |
| 1718089 | 742 | LEVER,PAPER,RETURN |
| 1835991 | 745 | COVER,CR |
| 1749768 | 746 | KEY SLOT FL ASSY.,CG86,EPPI |
| 1563742 | 747 | PRESSING PLATE,TUBE,C |
| 2216158 | 800 | SCANNER UNIT ASSY.,CJ66,EPPI,ASP |
| 1694135 | 801 | MAT,COVER,DOCUMENT |
| 1746910 | 804 | LABEL,INK,Position,EEB WE |
| 2190471 | 805 | FFC,MOTOR,SC,B |
| 2190472 | 806 | FFC,CIS,B |
| 1822131 | 807 | COVER,DOCUMENT,SC,C |
| 2209139 | 808 | HARNESS |
| 2172533 | 809 | MOTOR,Assy.,SC,C |
| 1865197 | 810 | CIS MODULE ASSY.,CJ60,ASP,EPPI |
| 1866394 | 812 | STAND SC ASSY,CJ65,ASP,EPPI |
| 1746184 | 814 | COVER,ASF |
